Agilent Technologies 7697A - Connect Cabling

26 Installation and First Startup
1 Installation
Connect Cabling
1 Connect the power cable. See Figure 4.
Figure 4 Back panel connections
2 Connect the LAN cable. See Figure 4.
3 Connect the APG Remote cable. See Figure 4 through
Figure 7.
8121-0940
G1530-60930
