Agilent Technologies 7697A - Install the Transfer Line to the Headspace

36 Installation and First Startup
1 Installation
Install the transfer line to the Headspace
1 Remove the front pneumatics cover.
a Remove the T- 20 screw that secures the cover in place.
b Pull the cover away from the chassis, then lift to
remove.
CAUTION
Wear clean, lint-free gloves to prevent contamination of parts with
dirt and skin oils.
Front pneumatics cover
