6 Installation and First Startup
1 Installation
Before You Begin
Before installing the headspace sampler (HS), review the
information below.
Tools required for installation
The following tools and parts are needed for installation.
The other necessary parts and tools are supplied with the
new instrument.
Personnel needed for installation
The instrument is heavy. When lifting or moving the
instrument, two persons are required.
Table 1 Tools and parts for installation
Tool Agilent part number Use
Required
Torx T-20 driver 5182-3465 Transfer line installation
Open-end wrenches:
• 7/16-inch (2)
• 5/16-inch
8710-0972
8710-0510
Swagelok fittings for gas connections, sample loop,
and transfer line
Tubing cutter 8710-1709 Cut 1/8-inch gas supply plumbing
Precision tubing cutter 5190-1442 Cut 1/16-inch stainless steel tubing
Included
1/4-in. x 3/16-in. wrench 8710-2618 Transfer line installation
Column cutting wafer 5181-7487 Transfer line installation
