Installation 1
Installation and First Startup 27
Cabling diagrams for Agilent GCs
Figure 5 HS–GC (LAN)–PC
Figure 6 HS–GC (GPIB)–PC
GC:
7890A, 7820A, 6890
with LAN, 6850,
5975T LTM
GC/MSD
HS
PC
LAN switch
or hub
LAN cable 8121-0940
LAN cable 8121-0940*
LAN cable
8121-0940
G1530-60930*
APG Remote
cable
*Included in ship kit.
GC
6890A GPIB
HS
PC
LAN switch
or hub
LAN cable
8121-0940
LAN cable 8121-0940*
G1530-60930*
APG Remote
cable
*Included in ship kit.
