Installation 1
Installation and First Startup 7
Parts supplied with the instrument
The headspace sampler ships with consumables and
hardware sufficient for typical installation and checkout. See
Table 2 below.
Table 2 Parts supplied with the headspace sampler
Description Part number Quantity Use
Wrench, open end 3/16-in. x 1/4-in. 8710-2618 1 Transfer line connection.
LAN cable 8121-0940 1 Communications.
Cable, APG remote, 9M/9M G1530-60930 1 Communications.
Flat bottom headspace vials, 20 mL, 100/pk 5182-0837 1 Checkout.
Crimp cap, headspace, Al, PTFE/Si septum,
20 mm, 100/pk
5183-4477 Checkout.
Ergonomic manual crimper for 20 mm caps 5040-4669 Checkout.
Leak Test Kit G4556-67010 1
Vial Pressurization Connection Kit
Tubing, post-drawn, 1650 mm 1530-2239 1 Connect HS Vial Pressure fitting to the gas
supply.
Nut, stainless steel, for 1/16-in. tubing 0100-0053 1 Connect the 1/16-in. end of the post-drawn
tubing to the HS Vial Pressure fitting.
Ferrule set, stainless steel, for 1/16-in. tubing 0100-1490 1
Nut and ferrule set, 1/8-in. Swagelok,
stainless steel
5181-7482 1 Connect the 1/8-in. end of the tubing to the
gas supply.
Transfer Line Connection Kit
Fused silica, deactivated, .530 mm id x 5 m
long
160-2535-5 1 Transfer line.
Fitting, internal reducer, 1/16-in. to 1/32-in. 0100-2594 1 Transfer line connection.
Ferrule, polyamide graphite 1/32-in. 0100-2595 1 Transfer line connection.
Transfer line support assembly G3504-60620 1 Support transfer line at GC inlet. Consists of
bracket, clamp, and knurled thumbscrew.
Tubing, post-drawn, 1650 mm 1530-2239 1 Connect HS Carrier fitting to the gas supply
from the GC inlet flow module.
Union SS 1/16-inch tubing 0100-0124 1 Connect the 1/16-in. end of the post-drawn
tubing to the open end of the GC inlet carrier
line.
Column cutting wafer 5181-7487 1 Trim fused silica transfer line.
