66 Installation and First Startup
2 First Startup
Figure 24 MS and MSD checkout chromatogram
TIC: 0201002.D
Abundance
Time
1000000
800000
600000
400000
200000
0
3.20 3.60 4.00 4.40 4.80 5.20 5.60 6.00 6.40
Dichlorobenzene
Nitrobenzene
t-Butyl disulfide
