Agilent Technologies 8719ET Programmer's Guide

Chapter 7 7-135
Programming Examples
Limit Line and Data Point Special Functions
Example:
Sending OUTPSEGAM may return the following:
5,
1, 1.900000000E+09, −9.900000E−01, 2.123456789E+09, 2.123456E+00
3, 2.300000000E+09, −10.00000E−01, 2.600000000E+09, 3.100000E+00
5, 3.200000000E+09, −10.00000E−01, 3.400000000E+09, 3.100000E+00
7, 4.300000000E+09, −10.00000E−01, 4.700000000E+09, 3.100000E+00
8, 5.000000000E+09, −10.00000E−01, 5.400000000E+09, 3.100000E+00
For an explanation of these results, see Table 7-18.
NOTE A new line feed character <
L
F
> is inserted after the segment number and
after each data pair.
Table 7-18 is an interpretation of the min/max data returned using the OUTPSEGAM
command.
Table 7-18 Example Output: OUTPSEGAM (min/max for all segments)
Segments
Reported
Segment
Number
Min Pt Stimulus
(Frequency)
Min Pt
Value (dB)
Max Pt Stimulus
(Frequency)
Max Pt
Value (dB)
5
1 1.9 GHz −.99 2.12 GHz 2.12
3 2.3 GHz −1.0 2.6 GHz 3.1
5 3.2 GHz −1.0 3.4 GHz 3.1
7 4.3 GHz −1.0 4.7 GHz 3.1
8 5.0 GHz −1.0 5.4 GHz 3.1
