A-6 AppendixA
Preset Conditions
Preset State
Table A-3 Response Conditions
Preset Conditions Preset Value
Meas Parameter (ES models):
Channel 1
S11
Channel 2
S21
Channel 3
S12
Channel 4
S22
Meas Parameter (ET models):
Channel 1
Reflection
Channel 2
Transmission
Channel 3
Reflection
Channel 4
Transmission
Conversion Off
Format Log Magnitude (all inputs)
Display Data
Color Selections
Same as before
Dual Channel Off
Active Channel Channel 1
Auxiliary Channel Off
Frequency Blank Disabled
Retrace Power
1
Standard
Test Set Switch (ES models only):
8753ES Option 011 N/A
8719/20/22ES Option 007 or 085 Hold
All other ES models Continuous
Split Display 2X
Intensity
If set to ≥15%, has no effect. If set
to < 15%, increases intensity to
15%.
Beeper: Done On
Beeper: Warning Off
D2/D1 to D2 Off
Preset
Preset
Preset
