Appendix A A-5
Preset Conditions
Preset State
Start Power:
8719ET/ES and 8720ET/ES −15.0 dBm
8719ET/ES and 8720ET/ES Option 007 −10.0 dBm
8719ET/ES and 8720ET/ES Option 400 −20.0 dBm
8722ET/ES −20.0 dBm
8722ET/ES Option 007 −15.0 dBm
8722ET/ES Option 400 −25.0 dBm
8753ET/ES −15.0 dBm
Power Slope Setting (8753ES only) 0 dB/GHz
Power Slope On/Off (8753ES only) Off
Power Span:
8719ET/ES and 8720ET/ES 20 dB
8722ET/ES 15 dB
8753ET/ES 25 dB
Coupled Power (ES models only) On
Coupled Channels On
Coupled Port Power
2
On
Power Range Auto/Manual
2
Auto
Power Range:
2
8720E series Range 0
8720E series, Option 400 Range 1
8753ET/ES Range 0
Number of Points 201
List Freq Sweep Mode Swept
Frequency List Empty
Edit Mode Start/Stop, Number of Points
1. Can be changed by pressing
.
2. Not valid on 8753ES Option 011.
Table A-2 Stimulus Conditions
Preset Conditions Preset Value
System
CONFIGURE MENU USER SETTINGS
PRESET SETTINGS STEP SWP ON
