Hardkey/Softkey Reference
Analyzer Functions
specifies the number of the disk unit in the disk drive that
is to be accessed in an external disk store or load routine.
This is used in conjunction with the GPIB address of the
disk drive, and the volume number, to gain access to a
specific area on a disk. The access hierarchy is GPIB
address, disk unit number, disk volume number.
displays response and stimulus values for all markers that
are turned on. Available only if no marker functions are
on, for example .
provides access to a series of menus for instrument and
active channel display functions. The first menu defines
the displayed active channel trace in terms of the
mathematical relationship between data and trace
memory. Other functions include auxiliary channel
enabling, dual channel display (overlaid or split), display
intensity, color selection, active channel display title, and
frequency blanking.
displays the current measurement data for the active
channel.
leads to a series of service tests for the display.
activates both forward and reverse measurements of
selected calibration standards.
activates both forward measurements (reflection and
transmission) of the thru standard from the selective
enhanced response calibration menus.
activates both reverse measurements of the thru standard
S22/S12 from the S11/S21 selective enhanced response
calibration menus. (ES only).
has two functions:
• It shows the current sequences in memory. To run a
sequence, press the softkey next to the desired
sequence title.
• When entered into a sequence, this command performs
a one-way jump to the sequence residing in the
specified sequence position (SEQUENCE 1 through 6).
jumps to a softkey position, not to a
specific sequence title. Whatever sequence is in the
selected softkey position will run when the
command is executed. This command
prompts the operator to select a destination sequence
position.
