8753ES Specifications and Characteristics
Corrected System Performance
Corrected System Performance
The specifications in this section apply for measurements made using 10 Hz IF bandwidth,
no averaging, and at an environmental temperature of 25 ±5 °C, with less than 1 °C
deviation from the calibration temperature. Assumes that an isolation calibration was
performed with an averaging factor of 16.
Table 1-1 System Dynamic Range, All Device Connector Types
8753ES, All Options, All Cal Kits, All Cables, 10 Hz IF BW
Description Specification Supplemental
Information
System Transmission Dynamic Range
a
a. The System Transmission Dynamic Range is calculated as the difference
between the receiver noise floor and the lesser of either: the source maximum
output or the receiver maximum input.
Standard (50 Ω)
30 kHz to 50 kHz 70 dB
50 kHz to 300 kHz 90 dB
300 kHz to 16 MHz 100 dB
16 MHz to 1.3 GHz 110 dB
1.3 GHz to 3 GHz 110 dB
3 GHz to 6 GHz 105 dB
Option 075 (75 Ω)
30 kHz to 50 kHz 68 dB
50 kHz to 300 kHz 90 dB
300 kHz to 16 MHz 96 dB
16 MHz to 1.3 GHz 106 dB
1.3 GHz to 3 GHz 106 dB
Option 014
30 kHz to 50 kHz 68 dB
50 kHz to 300 kHz 90 dB
300 kHz to 16 MHz 98 dB
16 MHz to 1.3 GHz 108 dB
1.3 GHz to 3 GHz 108 dB
3 GHz to 6 GHz 103 dB
