Agilent Technologies 8720ES Reference Guide

2-18
8753ET Specifications and Characteristics
Instrument Specifications
General Information
Table 2-16 General Information
8753ET General Information
Description Specification Supplemental Information
Display Range
Magnitude ± 200 dB (at 20 dB/div), max
Phase ± 180°, max
Polar 10 pico units, min
1000 units, max
Display Resolution
Magnitude 0.001 dB/div, min
Phase 0.1°/div, min
Reference Level Range
Magnitude ± 500 dB, max
Phase ± 360°, max
Reference Level Resolution
Magnitude 0.001 dB, min
Phase 0.01°, min
Marker Resolution
Magnitude 0.001 dB, min
Phase 0.01°, min
Polar 0.01 mUnit, min; 0.01, min
