Agilent Technologies 8720ES Reference Guide

1-28
8753ES Specifications and Characteristics
Instrument Specifications
Speed Parameters
Table 1-27 8753ES Measurement and Data Transfer Speed Performance
Typical Time for Completion (ms)
Description Number of Points
51 201 401 1601
Typical Time for Completion (in ms), Center 1 GHz, Span 10 MHz, IFBW=6000
Uncorrected 32 70 121 423
1-port and Enhanced Response cal
a
a. S11 1-port calibration, with a 6 kHz IF bandwidth. Includes system retrace time, but
does not include bandswitch time. Time domain gating is assumed off.
35 71 1271 440
2-port cal
b
b. S21 measurement with full 2-port calibration, using a 6 kHz IF bandwidth. Includes
system retrace time and RF switching time, but does not include bandswitch time. Time
domain gating is assumed off.
62 139 240 848
Typical Time for Completion (in ms), Start 30 kHz, Stop 3 GHz, IFBW=6000
Uncorrected 202 270 304 615
1-port and Enhanced Response cal
a
202 270 304 615
2-port cal
b
402 540 607 1237
Typical Time for Completion (in ms), Start 30 kHz, Stop 6 GHz, IFBW=6000
Uncorrected 310 380 415 658
1-port and Enhanced Response cal
a
310 380 415 658
2-port cal
b
618 757 829 1315
Time Domain
c
(increase over uncorrected sweep time)
c. Option 010 only, gating off.
Conversions 12 42 86 378
Gating (Frequency Domain) 14 40 80 349
GPIB Data Transfer
d
:
d. Measured with HP Omnibook 7100 Pentium Pro computer.
Binary (Internal) 10 16 21 58
IEEE754 floating point format
32 bit 11 19 28 83
64 bit 13 26 42 141
ASCII 35 112 214 831
