1-16
8753ES Specifications and Characteristics
Instrument Specifications
Test Port Input
Table 1-14 Test Port Input
8753ES Test Port Input
Description Specification Supplemental Information
Frequency Range
Standard 30 kHz to 3.0 GHz 10 kHz to 3 GHz, typ.
Option 006 30 kHz to 6.0 GHz 10 kHz to 6 GHz, typ.
Frequency Response, Non-Ratio Measurement (A or B)
300 kHz to 3 GHz ±1 dB at preset power level
3 GHz to 6 GHz ±2 dB at preset power level
Impedance
Standard 50 , nominal.
Return Loss
Standard See uncorrected load match
chart
Maximum Input Level
Standard +10 dBm
Compression See dynamic accuracy chart
Damage Level
Standard > +26 dBm or > 35 Vdc, typ.
Noise Floor
a
a. RMS value of a linear magnitude trace expressed in dBm, with the source power set to
minimum to minimize the effects of crosstalk.
8753ES
300 kHz to 3 GHz
3 kHz IF Bandwidth ≤−82 dBm
10 Hz IF Bandwidth ≤−102 dBm ≤−110 dBm, typ.
3 GHz to 6 GHz
3 kHz IF Bandwidth ≤−77 dBm
10 Hz IF Bandwidth ≤−97 dBm ≤−105 dBm, typ.
8753ES Option 075
300 kHz to 3 GHz
3 kHz IF Bandwidth ≤−80 dBm
10 Hz IF Bandwidth ≤−100 dBm ≤−110 dBm, typ.
