Agilent Technologies 8720ES Reference Guide

1-10
8753ES Specifications and Characteristics
Instrument Specifications
Instrument Specifications
Uncorrected Port Performance
Table 1-8 7-mm Device Connector Type
8753ES (7-mm, 50 Ω), Standard and Option 006
Description
Specification
30 kHz to
50 kHz
50 kHz to
300 kHz
300 kHz to
1.3 GHz
1.3 GHz to
3 GHz
3 to 6 GHz
(Opt 006
only)
Directivity
a
(dB)
a. Does not include the effect of the cable set on the test ports.
15, typ. 20, typ. 35 30 25
Source Match
a
(dB)
10, typ. 18, typ. 16 16 14
Load Match
a
(dB)
10, typ. 18, typ. 18 16 14
Reflection
Tracking
a
(dB)
±2.5, typ. ±2.5, typ. ±1.0 ±1.0 ±1.5
Transmission
Tracking
a
(dB)
±2.5, typ. ±2.5, typ. ±1.0 ±1.0 ±1.5
Tracking Stability
(Ratio Measurement)
Magnitude (dB) .002/°C, typ. .002/°C, typ. .002/°C, typ. .002/°C, typ. 0.04/°C, typ.
Phase (deg) .004/°C, typ. .004/°C, typ. .004/°C, typ. .004/°C, typ. 0.20/°C, typ.
Crosstalk
b
(dB)
b. Measurement conditions: Normalized to a thru, measured with two shorts, 10 Hz IF
bandwidth, averaging factor of 8, alternate mode, source power set to the lesser of the
maximum power out or the maximum receiver power.
60, typ. 90, typ. 100 100 90
