2-7
8753ET Specifications and Characteristics
Instrument Specifications
Test Port Output
Table 2-4 Test Port Output
8753ET Test Port Output
Description Specification Supplemental Information
Frequency
Range
Standard 300 kHz to 3.0 GHz 10 kHz to 3 GHz, typ.
Option 006 300 kHz to 6.0 GHz 10 kHz to 6 GHz, typ.
Resolution 1 Hz
Stability
Standard ±7.5 ppm, 0° to 55 °C, typ.
±3 ppm/year, typ.
Option 1D5 ±0.05 ppm, 0° to 55 °C, typ.
±0.5 ppm/year, typ.
CW Accuracy ±10 ppm at 25 °C ±5 °C
Output Power (above 300 kHz)
Level Accuracy
a
a. Absolute power accuracy at a given power level. Includes absolute accuracy and relative
flatness across frequency.
With Option 004 Attenuator ±1.0 dB at −10 dBm output level
Without Attenuator ±1.0 dB at −5 dBm output level
Maximum Leveled Power
b
b. At any given frequency, the achievable power while remaining leveled. Applies to CW
mode only.
With Option 004 Attenuator +10 dBm, char.
Without Attenuator +5 dBm, char.
Power Range
c
c. Power to which the source can be set and phase lock is assured.
With Option 004 Attenuator −85 to +10 dBm
Without Attenuator −20 to +5 dBm
Power Sweep Range
With Option 004 Attenuator 25 dB 33 dB, typ.
Without Attenuator 25 dB 33 dB, typ.
