1-12
8753ES Specifications and Characteristics
Instrument Specifications
Test Port Output
Table 1-10 Test Port Output
8753ES Test Port Output
Description Specification Supplemental Information
Frequency
Range
Standard 30 kHz to 3.0 GHz 10 kHz to 3 GHz, typ.
Option 006 30 kHz to 6.0 GHz 10 kHz to 6 GHz, typ.
Resolution 1 Hz
Stability
Standard ±7.5 ppm, 0˚ to 55˚C, typ.
±3 ppm/year, typ.
Option 1D5 0.05 ppm, 0˚ to 55˚C, typ.
±0.5 ppm/year, typ.
CW Accuracy ±10 ppm at 25˚C ±5 ˚C
Output Power
a
(above 300 kHz)
a. Source output performance on port 1 only. Port 2 output performance is a characteristic.
Level Accuracy
b
b. Absolute power accuracy at a given power level. Includes absolute accuracy and relative
flatness across frequency.
Standard ±1.0 dB at 0 dBm output level
Option 075 ±1.0 dB at 0 dBm output level
Maximum Leveled Power
c
c. At any given frequency, the achievable power while remaining leveled. Applies to CW
mode only.
Standard +10 dBm, char.
Option 075 +8 dBm, char.
Option 014 +8 dBm, char.
Power Range
d
d. Power to which the source can be set and phase lock is assured.
Standard 85 to +10 dBm
Option 075 85 to +8 dBm
Option 014 85 to +8 dBm
Power Sweep Range
Standard 25 dB 33 dB, typ.
Option 075 23 dB 31 dB, typ.
Option 014 23 dB 31 dB, typ.
