Agilent Technologies 8720ES Reference Guide

1-11
8753ES Specifications and Characteristics
Instrument Specifications
Table 1-9 Type-N (75 Ω) Device Connector Type
8753ES (Type-N, 75Ω), Option 075
Description Specification
30 kHz to
50 kHz
50 kHz to
300 kHz
300 kHz to
1.3 GHz
1.3 GHz to
3 GHz
3 to 6 GHz
(Opt 006 only)
Directivity
a
(dB)
15, typ. 20, typ. 35 30 N/A
Source Match
a
(dB)
10, typ. 18, typ. 16 16 N/A
Load Match
a
(dB)
10, typ. 18, typ. 18 16 N/A
Reflection
Tracking
a
(dB)
±2.5, typ. ±2.5, typ. ±1.0 ±1.0
N/A
Transmission
Tracking
a
(dB)
±2.5, typ. ±2.5, typ. ±1.0 ±1.0
N/A
Tracking Stability
(Ratio Measurement)
Magnitude (dB) .002/°C, typ. .002/°C, typ. .002/°C, typ. .002/°C, typ. 0.04/°C, typ.
Phase (deg) .004/°C, typ. .004/°C, typ. .004/°C, typ. .004/°C, typ. 0.20 °/°C, typ.
Crosstalk
b
(dB)
60, typ. 90, typ. 100 100 N/A
a. Does not include the effect of the cable set on the test ports.
b. Measurement conditions: Normalized to a thru, measured with two shorts, 10 Hz IF
bandwidth, averaging factor of 8, alternate mode, source power set to the lesser of the
maximum power out or the maximum receiver power.
