8753ET Specifications and Characteristics
Instrument Specifications
Instrument Specifications
Uncorrected Port Performance
Table 2-3 Type-N (50 Ω) Device Connector Type
8753ET (Type-N, 50 Ω)
Description
Specification
300 kHz to
1.3 GHz
1.3 to 3 GHz 3 to 6 GHz
(Opt 006 only)
Directivity
a
(dB)
a. Does not include the effect of the cable set on the test ports.
30 24 19
Source Match
a
Standard (dB) 25 20 14
Option 004 (dB) 23 18 14
Load Match
a
(dB)
24 19 16
Reflection
Tracking
a
(dB)
±1.0 ±1.0 ±2.0
Transmission
Tracking
a
(dB)
±1.5 ±1.5 ±2.5
Tracking Stability
(Ratio Measurement)
Magnitude (db) .002/°C, typ. .002/°C, typ. .004/°C, typ.
Phase (deg) .004/°C, typ. .004/°C, typ. .020/°C, typ.
Crosstalk
b
(dB)
b. Measurement conditions: Normalized to a thru, measured with two shorts, 10 Hz IF
bandwidth, averaging factor of 8, alternate mode, source power set to the lesser of the
maximum power out or the maximum receiver power.
100 100 90
