8753ES Specifications and Characteristics
Instrument Specifications
Table 1-28 8753ES Recall and Sweep Speed Performance
Operations Channel Points
Raw
Offset
Total Time,
typical (secs)
Recall-Only
Time, typical
(secs)
Blank
Off
Blank
On
Blank
Off
Blank
On
Error Correction
ON
Recall and Sweep Single Chan. 201 On 0.389 0.260 0.250 0.126
Recall and Sweep Single Chan. 201 Off 0.340 0.210 0.201 0.077
Sweep only (no Recall) Single Chan. 201 N/A 0.139 0.134 N/A N/A
Recall and Sweep Single Chan. 1601 On 1.480 1.347 0.632 0.506
Recall and Sweep Single Chan. 1601 Off 1.102 0.969 0.254 0.128
Sweep only (no Recall) Single Chan. 1601 N/A 0.848 0.841 N/A N/A
Recall and Sweep Dual Chan. 201 On 0.539 0.389 0.357 0.215
Recall and Sweep Dual Chan. 201 Off 0.489 0.328 0.308 0.154
Sweep only (no Recall) Dual Chan. 201 N/A 0.182 0.174 N/A N/A
Recall and Sweep Dual Chan. 1601 On 2.386 2.219 1.208 1.049
Recall and Sweep Dual Chan. 1601 Off 2.007 1.839 0.829 0.669
Sweep only (no Recall) Dual Chan. 1601 N/A 1.178 1.170 N/A N/A
Error Correction
OFF
Recall and Sweep Single Chan. 201 On 0.240 0.147 0.170 0.082
Recall and Sweep Single Chan. 201 Off 0.227 0.134 0.157 0.069
Sweep only (no Recall) Single Chan. 201 N/A 0.070 0.065 N/A N/A
Recall and Sweep Single Chan. 1601 On 0.675 0.587 0.252 0.168
Recall and Sweep Single Chan. 1601 Off 0.581 0.491 0.157 0.073
Sweep only (no Recall) Single Chan. 1601 N/A 0.423 0.419 N/A N/A
Recall and Sweep Dual Chan. 201 On 0.306 0.170 0.235 0.104
Recall and Sweep Dual Chan. 201 Off 0.281 0.145 0.211 0.080
Sweep only (no Recall) Dual Chan. 201 N/A 0.071 0.066 N/A N/A
Recall and Sweep Dual Chan. 1601 On 0.802 0.692 0.377 0.273
Recall and Sweep Dual Chan. 1601 Off 0.613 0.503 0.188 0.084
Sweep only (no Recall) Dual Chan. 1601 N/A 0.424 0.419 N/A N/A
Instrument State: CF = 1 GHz, Span = 2 MHz, IF BW = 6 kHz. GPIB commands sent for timing are
Recall;OPC?;SING; or, for sweep only, OPC?;SING;.
