8-3
Preset State and Memory Allocation
Preset State
Table 8-1 Preset Conditions
Preset Conditions Preset Value
Analyzer Mode
Analyzer Mode Network Analyzer Mode
Frequency Offset Operation Off
Offset Value 0
Harmonic Operation Off
Stimulus Conditions
Sweep Type Linear Frequency
Display Mode Start/Stop
Trigger Type Continuous
External Trigger Off
Sweep Time 87.5 ms, Auto Mode
Start Frequency ES: 30 kHz. ET: 300 kHz
Frequency Span ES: 2999.97 MHz
ET: 2999.7 MHz
Frequency Span (Opt. 006) ES: 5999.97 MHz
ET: 5999.7 MHz
Start Time 0
Time Span 75.375 ms
CW Frequency 1000 MHz
Source Power ES: 0 dBm
ET: −10 dBm
Power Slope (ES Only) 0 dB/GHz; Off
Start Power −15.0 dBm
Power Span 25 dB
Coupled Channel Power On
Source Power On
Coupled Channels On
Coupled Port Power (ES Only) On
Power Range (ES Only) Auto; Range 0
Number of Points 201
List Freq Sweep Mode Swept
