1-24
8753ES Specifications and Characteristics
Instrument Specifications
Table 1-23 General Information
8753ES General Information
Description Supplemental Information
System Bandwidths
IF bandwidth settings 6000 Hz, nom.
3700 Hz, nom.
3000 Hz, nom.
1000 Hz nom.
300 Hz, nom.
100 Hz, nom.
30 Hz, nom.
10 Hz, nom.
Rear Panel
External Auxiliary Input
Connector Female BNC
Range ±10 V, typ.
External Trigger Triggers on a positive or negative TTL transition or contact
closure to ground.
Damage Level < −0.2 V; > +5.2 V, typ.
Limit Test Output Female BNC.
Damage Level < −0.2 V; > +5.2 V, typ.
Test Sequence Output Outputs a TTL signal which can be set to a TTL high pulse
(default) or low pulse at end of sweep; or a fixed TTL high or
low. If limit test is on, the end of sweep pulse occurs after the
limit test is valid. This is useful when used in conjunction with
test sequencing.
Test Set Interconnect 25-pin-D-sub (DB-25) female; use for external special test sets
(K36, K39, etc.)
Measure Restart Floating closure to restart measurement.
External AM Input ±1 volt into a 5 kΩ resistor, 1 kHz maximum, resulting in
approximately 8 dB/volt amplitude modulation.
High Stability Frequency
Reference Output (10 MHz)
(Option 1D5)
Frequency 10.0000 MHz, char.
Frequency Stability
(0 °C to 55 °C)
±0.05 ppm, char.
Daily aging rate (after 30 days)
< 3 x 10
−9
/day, char.
Yearly aging rate ±0.5 ppm/year, char.
Ouput ≥0 dBm, char.
Output Impedance 50 Ω, nom.
