1-26
8753ES Specifications and Characteristics
Instrument Specifications
Table 1-25 General Information
8753ES General Information
Description Specification
Front Panel
Display Pixel Integrity
Red, Green, or Blue Pixels Red, green, or blue “stuck on” pixels may
appear against a black background. In a
properly working display, the following will
not occur:
• complete rows or columns of stuck pixels
• more than 5 stuck pixels (not to exceed a
maximum of 2 red or blue, and 3 green)
• 2 or more consecutive stuck pixels
• stuck pixels less than 6.5 mm apart
Dark Pixels Dark “stuck on” pixels may appear against a
white background. In a properly working
display, the following will not occur:
• more than 12 stuck pixels (not to exceed a
maximum of 7 red, green, or blue)
• more than one occurrence of 2
consecutive stuck pixels
• stuck pixels less than 6.5 mm apart
