Agilent Technologies 8720ES Reference Guide

2-4
8753ET Specifications and Characteristics
Corrected System Performance
Table 2-2 Type-N (50 Ω) Device Connector Type
Network Analyzer: 8753ET Standard or Option 004 Attenuator
Calibration Kit: 85032B/E (Type-N, 50 Ω)
Cables: 8120-5639
Calibration: See Below
IF BW = 10 Hz, Avg = off, Temp = 25 ± 5 °C with < 1 °C deviation from cal temp, Isol cal with avg = 8
Description
Specification
300 kHz to 1.3 GHz 1.3 to 3 GHz 3 to 6 GHz
(Opt 006 only)
Reflection Measurements
a
Directivity (dB) 50 47 40
Source Match (dB) 42 36 31
Load Match
One-Port Cal 24 19 16
Tracking
Magnitude (dB) ±(0.009 + .01/°C) ±(0.019 + .02/°C) ±(0.07 + .03/°C)
Phase (deg) ±(0.059 + .05/°C) ±(0.125 + .05/°C) ±(0.462 + .2/°C)
Transmission Measurements
b
Source Match (dB)
Enhanced Response Cal 42 36 31
Response Only Cal
Standard 25 20 14
Option 004 23 18 14
Load Match 24 19 16
Tracking
Enhanced Response Cal
Magnitude (dB) ±(0.006 + .01/°C) ±(0.018 + .02/°C) ±(0.054 + .03/°C)
Phase (deg) ±(0.0396 + .05/°C) ±(0.119 + .05/°C) ±(0.389 + .20/°C)
Response Only Cal
Standard
Magnitude (dB) ±(0.031 + .01/°C) ±(0.1 + .02/°C) ±(0.27 + .03/°C)
Phase (deg) ±(0.203 + .05/°C) ±(0.66 + .05/°C) ±(1.78 + .20/°C)
Option 004
Magnitude (dB) ±(0.039 + .01/°C) ±(0.122 + .02/°C) ±(0.27 + .03/°C)
Phase (deg) ±(0.255 + .05/°C) ±(0.804 + .05/°C) ±(1.78 + .20/°C)
Uncertainty graphs are on the following page.
a. One-port or enhanced response calibration.
b. Enhanced response or response only calibration.
