2-10
8753ET Specifications and Characteristics
Instrument Specifications
Table 2-7 Test Port Output
8753ET Test Port Output
Description Specification Supplemental Information
Signal Purity
2nd Harmonic 16 MHz to 1.5 GHz (source frequency)
16 MHz to 3 GHz
(Option 006, source frequency)
at the maximum output
power
< −25 dBc, char. (Option 002)
at 10 dB below maximum
output power
< −40 dBc, typ.
at 20 dB below maximum
output power
< −50 dBc, typ.
3rd Harmonic 16 MHz to 1 GHz (source frequency)
16 MHz to 2 GHz
(Option 006, source frequency)
at the maximum output
power
< −25 dBc, char. (Option 002)
at 10 dB below maximum
output power
< −40 dBc, typ.
at 20 dB below maximum
output power
< −50 dBc, typ.
Non-harmonic Spurious
Mixer Related
at maximum output power < −30 dBc, typ.
at 20 dB below maximum
output power
< −55 dBc, typ.
