2-21
8753ET Specifications and Characteristics
Instrument Specifications
Table 2-19 General Information
8753ET General Information
Description Specification Supplemental Information
Rear Panel
External Reference In
Input Frequency 1, 2, 5, and 10 MHz ± 200 Hz at 10 MHz
Input Power −10 dBm to +20 dBm, typ.
Input Impedance 50 Ω, nom.
VGA Video Output 15-pin mini D-Sub; female. Drives
VGA compatible monitors.
GPIB Type-57, 24-pin; Microribbon
female
Parallel Port 25-pin D-Sub (DB-25); female;
may be used as printer port or
general purpose I.O. port
RS232 9-pin D-Sub (DB-9); male
Mini-DIN Keyboard/Barcode Reader 6-pin mini DIN (PS/2); female
Line Power A third-wire ground is required.
Frequency 47 Hz to 66 Hz
Voltage at 115 V setting 90 V to 132 V 115 V, nom.
Voltage at 220 V setting 198 V to 265 VAC 230 V, nom.
VA Maximum 350 VA max
Front Panel
RF Connectors Type-N, 50 ohm
Probe Power 3-pin connector; male
Positive Supply 400 mA, max +15 V ± 2%, char.
the maximum combined load for
both probe connectors, char.
Negative Supply 300 mA, max − 12.6 V ± 5%, char.
the maximum combined load for
both probe connectors, char.
