Agilent Technologies 89410A Service Guide

1-54
Troubleshooting the Analyzer
To troubleshoot intermittent failures
failure.See ‘’Fault Log Messages’’ on page 7-9for detailed
descriptions of each fault log message.
Failing Message Displayed Probable Faulty
Assembly
Next Test
System Error
System Error during Calibration
A40 CPU
A47 DSP/Display
Controller
A42 Memory
A30 Digital Source
A50 Digital Filter
A43 Expanded Memory
A71 Pass Through
Initial verification,
page 1-10
Internal Disk Trk0 Failure A101 Disk Drive
A42 Memory
Disk drive cable
Disk drive, page 1-88-
NVRAM or Battery Failure
Floppy Controller Timeout
memory battery
A42 Memory
Memory battery,
page 1-93-
Input Tripped User over-voltage
connected to input
A10 Input
Source Tripped User over-voltage
connected to source
A35 Analog Source
Real Time Clock Timeout A42 Memory
CPU Failure
CPU Board Bus Error
A40 CPU
Memory Board Bus Error
Memory Board Failure
A42 Memory
Display/DSP Board Bus Error
DSP Failure
Display Failure
A47 DSP/Display
Controller
Digital Source Board Bus Error
Digital Source Board Failure
A30 Digital Source
Internal Control Path 3 Failure A35 Analog Source
A36 Trigger
A30 Digital Source
Front-end control,
page 1-60
Trigger Board Failure A36 Trigger
A35 Analog Source
A30 Digital Source
Front-end control,
page 1-60
Sample/Capture RAM Board Bus Error
Sample/Capture RAM Board Failure
A55/A56 Sample RAM
Pass Thru Board Bus Error
Pass Thru Board Failure
A71 Pass Through
Digital Filter Board Bus Error
Digital Filter Board Failure
A50 Digital Filter
