1-5
Troubleshooting the Analyzer
†ITT Pomona Electronics, 1500 East Ninth Street, Pomona, CA 91769 U.S.A. (714) 469-2900 FAX (714) 629-3317
‡Individual extender boards cannot be ordered. To order all three extender
boards in this kit, order
Agilent 89410-66515.
††See the following for assembly.
Recommended Test Equipment (continued)
Logic Probe TTL/CMOS Agilent 545A
Alternate
Agilent 5006A
Agilent 5005A/B
Oscilloscope Bandwidth ≥150 MHz
Vertical sensitivity 10 mV/div
Input coupling AC, DC, 50 Ω, 1 MΩ
Trigger Ext, Int
Agilent 54111D
Oscilloscope Probe Input R ≥1MΩ
Division Ratio 1:1
Agilent 10438A
Oscilloscope Probe Input R ≥1MΩ
Division Ratio 10:1
Agilent 10431A
50 Ω Feedthrough Termination
(2 for opt AY7)
Accuracy ±0.2% Agilent 11048C
(2) 50 Ω Termination ±2% at dc Pomona Model 3840-50 †
Alternate
Agilent 11048C with
Agilent 1250-0774
ThinLAN Transceiver AUI to ThinLAN adapter Agilent 28641B
Cables (4) 50 Ω BNC
Test clips-to-double banana plug
Agilent 8120-1840
Agilent 11002A
Adapters BNC(f)-to-Dual Banana Plug
N(m)-to-BNC(f) (2)
Test Clips-to-BNC(f)
BNC Tee
N(f)-to-BNC(f)
BNC(f)-to-Dual Banana Plug(m)
BNC(f)-to-BNC(f)
Agilent 1251-2816
Agilent 1250-0780
Pomona Model 2631 †
Agilent 1250-0781
Agilent 1250-1536
Agilent 1251-2277
Agilent 1250-0080
Service Kit
Includes
A10/A35 extender board
A36/A60 extender board
A61 extender board
Motherboard cable extraction tool
Plastic screw driver
Flat-edge adjustment tool
SMB extender cable (2)
BNC(m)-to-SMB(f) cable (2)
SMB(m)-to-SMB(m) adapter (2)
Agilent 89410-84401
Includes
Agilent 89410-B1001‡
Agilent 89410-B1002‡
Agilent 89410-B1008‡
Agilent 8710-2050
Agilent 8710-2056
Agilent 8710-1928
Agilent 03585-61601
Agilent 03585-61616
Agilent 1250-0669
10 kW Series Resistor †† Value: 10 kΩ
Accuracy: 1%
Power: 0.125 Ω
Agilent 0757-0442
CPU/Memory Service Utility
Disk
Agilent 89410-19463
