Agilent Technologies 89410A - To Remove CPU and Memory

3-8
Replacing Assemblies
To remove CPU and memory
To remove CPU and memory
1
Using a T-10 torx driver, remove the five screws from the #6
cover.
2
Pull the assemblies out of the card nest and disconnect the
cables. The cables can be pulled about two inches out of
the card nest.
