3-12
Replacing Assemblies
To place the A82 in the test position
To place the A82 in the test position
1
Remove the front panel (see ‘’To remove front
panel’’page 3-10).
2
Using a T-15 torx driver, remove the screw from the back of
the top cover. Slide the cover off.
3
Using a 2 point posidrive, remove the screw from both end
caps of the right side strap handle. Remove the strap
handle and side cover.
4
Using a T-15 torx driver, remove the four screws from the
power supply shield. Remove the power suppply shield.
To Next Page
