Agilent Technologies 89410A Service Guide

1-64
Troubleshooting the Analyzer
To troubleshoot source and calibrator out failures
e If the signals are correct, the A35 Analog Source is probably
faulty.
f If any of the signals are incorrect, the A30 Digital Source assembly
is probably faulty.
Test Location Signal Name
A91 J6 pin 12B OFF[0]
A91 J6 pin 12C OFF[1]
A91 J6 pin 13B OFF[2]
A91 J6 pin 13C OFF[3]
A91 J6 pin 14B OFF[4]
A91 J6 pin 14C OFF[5]
A91 J6 pin 15B OFF[6]
A91 J6 pin 18A NOFFWR
