Agilent Cary 8454 UV-Visible Spectroscopy System Operator’s Manual 31
Introduction to Your System 2
General Purpose Agilent ChemStation Software for UV-Visible Spectroscopy — Overview
User Interface Elements
Your general purpose Agilent ChemStation software for UV-Visible
spectroscopy facilitates operation of your diode-array-based UV-Visible
spectrophotometer in daily routine operation. The focus of this software is on
ease-of-use and ease-of-learning. A graphical user interface visualizes the
spectrophotometer operation and usage. This user interface consists of a
number of elements as described in the following sections.
Menu bar
Data files
Analysis panel
Modes
Tool bar
Method name
Instrument panel
Tabular results
Navigation bar
Spectra
