Meas Setup
Meas Method Allows you to select the measurement method.
Above
Threshold Lvl
Selects the user defined threshold level or default level
(-3.00 dB) as the criteria in making the measurement.
Measured
Burst Width
This measurement method is not available for the
following radio standards: IS95, J-STD-008,
cdma2000-SR1, cdma2000-SR3, W-DCMA 3GPP.
Key Access:
Meas Setup
Table 2-7 Burst Power Default Settings for Radio Standards
Standard Format Device Method Sweep
Time
Burst
Width
Threshold
Level
Resolution
BW
Video
BW
None N/A N/A
ATL
1
640
µ
sN/A
−
30 dB 3 MHz Wide
Open
IS95 BTS/
MS
ATL
2
2 ms N/A
−
30 dB 3 MHz Wide
Open
GSM/
EDGE
N/A BTS/
MS
MBW
3
2 ms N/A -20 dB 300 kHz 300
kHz
W-CDMA 3GPP BTS/
MS
ATL
2
2 ms N/A
−
30 dB 5 MHz Wide
Open
cdma2000
SR1 BTS/
MS
ATL
2
2 ms N/A
−
30 dB 3 MHz Wide
Open
cdma2000 SR3 BTS/
MS
ATL
2
2 ms N/A
−
30 dB 5 MHz Wide
Open
NADC N/A BTS
MBW
3
10 ms Auto -30 dB 100 kHz Wide
Open
NADC N/A MS
ATL
2
6 ms N/A -30 dB 100 kHz Wide
Open
PDC N/A BTS
MBW
3
10 ms Auto -30 dB 100 kHz Wide
Open
PDC N/A MS
MBW
3
6 ms N/A -30 dB 100 kHz Wide
Open
Bluetooth™ DH1,DH3,
DH5
N/A N/A N/A N/A N/A 3 MHz Wide
Open
1. Above threshold level
2. Above threshold level
3. Measured Burst Width
