144 Chapter 2
Front-Panel Key Reference
Meas Setup
Range
On Off
Allows you to select from the 20 ranges in the range
table. When a range has been selected, the values of the
range table parameters will appear on the
Range Table
menu keys. If
Range is set to On, the selected range
values will be used in your measurement. If
Range is
set to
Off, the selected range values will not be used.
The range parameters are listed in the table above.
Key Access:
Meas Setup, Range Table
Start Freq
Allows you to set the start frequency for the selected
range.
Key Access:
Meas Setup, Range Table
Stop Freq
Allows you to set the stop frequency for the selected
range.
Key Access:
Meas Setup, Range Table
Res BW
Auto Man
Allows you to set the resolution bandwidth for the
selected range. When
Auto is selected, the analyzer
determines the optimum setting, while
Man allows you
to enter the setting.
Key Access:
Meas Setup, Range Table
Video BW
Auto Man
Allows you to set the video bandwidth for the selected
range. When
Auto is selected, the analyzer determines
the optimum setting, while
Man allows you to enter the
setting.
Key Access:
Meas Setup, Range Table
Range Start Freq
(GHz)
Stop Freq
(GHz)
Res BW
(kHz)
Video BW Sweep
Time
Absolute
Limit
Peak
Threshold
Peak
Excursion
1 1.920 1.980 1200 Auto Auto -50 dBm -90 dBm 6 dB
2 1.894 1.920 510 Auto Auto -50 dBm -90 dBm 6 dB
3 2.100 2.102 100 Auto Auto -50 dBm -90 dBm 6 dB
4 2.175 2.180 100 Auto Auto -50 dBm -90 dBm 6 dB
5 0.800 1.000 4000 Auto Auto -50 dBm -90 dBm 6 dB
6-20 1.5 2.5 Auto Auto Auto -50 dBm -90 dBm 6 dB
