148 Chapter 2
Front-Panel Key Reference
Meas Setup
Offset/Limits Accesses the following parameters for offset frequency settings and
pass/fail tests:
Offset, Start Freq, Stop Freq, Sweep Time, Res BW, and
Limits. The following Tables show the default settings for BTS and MS
measurements.
Key Access:
Meas Setup
Offset
A B C D E
Allows you to select an offset that will determine the
settings of the parameters in the Offset/Limits key
menus. The default settings for 5 sets of offsets (A
through E) for both MS and BTS measurements are
shown in Table 2-1, and Table 2-2. Press Offset until
the letter of the desired offset (A, B, C, D or E) is
underlined.
Start Freq
On Off
Allows you to specify the limit (start frequency) for the
upper segment of the specified offset pair, and to toggle
this function between
On and Off for each offset.
Stop Freq Allows you to specify the limit (stop frequency) for the
upper segment of the specified offset pair.
Table 2-1 Offsets & Limits Defaulted for BTS Measurements
Offset Start
Freq
(MHz)
Stop
Freq
(MHz)
Sweep
Time
(us)
Res BW
(kHz)
Abs
Start
(dBm)
Abs
Stop
(dBm)
Rel
Start
(dBc)
Rel
Stop
(dBc)
Fail
Mask
Meas
BW
(MHz)
A, On 2.515 2.715 Auto 30.00 −14.00 −14.00 −30.00 −30.00 Abs 1
B, On 2.715 3.515 Auto 30.00 −14.00 −26.00 −30.00 −30.00 Abs 1
C, On 3.515 4.000 Auto 30.00 −26.00 −26.00 −30.00 −30.00 Abs 1
D, Off 4.000 7.500 Auto 1000.0 −13.00 −13.00 −30.00 −30.00 Abs 20
E, Off 7.500 12.500 Auto 1000.0 −13.00 −13.00 −30.00 −30.00 Abs 1
Table 2-2 Offsets & Limits Defaulted for MS Measurements
Offset Start
Freq
(MHz)
Stop
Freq
(MHz)
Sweep
Time
(us)
Res BW
(kHz)
Abs
Start
(dBm)
Abs
Stop
(dBm)
Rel
Start
(dBc)
Rel
Stop
(dBc)
Fail
Mask
Meas
BW
(MHz)
A, On 2.515 3.485 Auto 30.00 −71.07 −71.07 −35.23 −49.78 AND 1
B, On 4.000 7.500 Auto 1000.0 −55.84 −55.84 −35.50 −39.00 AND 1
C, On 7.500 8.500 Auto 1000.0 −55.84 −55.84 −39.00 −49.00 AND 1
D, Off 8.500 12.500 Auto 1000.0 −55.84 −55.84 −49.00 −49.00 AND 1
E, Off 12.500 15.000 Auto 1000.0 −55.84 −55.84 −49.00 −49.00 AND 1
