172 Chapter 2
Front-Panel Key Reference
Preset
Stop Frequency
E4401B and E4411B
E4402B and E4403B
E4404B
E4405B
E4407B and E4408B
1.5 GHz
3.0 GHz
6.7 GHz
13.2 GHz
26.5 GHz
State Registers unaffected
Segmented Sweep off
Sweep
Points
continuous
Sweep Time
E4401B and E4411B
E4402B and E4403B
E4404B
E4405B
E4407B and E4408B
4 ms (auto coupled)
5 ms (auto coupled)
16.75 ms (auto coupled)
33 ms (auto coupled)
265 ms (auto coupled)
Sweep 401
Threshold level –90 dBm, display off
Title cleared
Trace 1 clear-write
Trace 2 blank, at bottom of display
Trace 3 blank, at bottom of display
Trigger free run
Trig Delay Off 1
µ
sec
Trig Offset Off 0 sec
VBW/RBW ratio 1.000 X (auto-coupled)
Video averaging off
Video bandwidth 3 MHz (auto-coupled)
1. E4401B, E4402B without Option UKB, E4403B, and E4411B have fixed AC
coupling. E4407B without Option UKB and E4408B have fixed DC coupling.
Table 2-8 Factory Preset Conditions (Continued)
To Next Page
