124 Appendix B
SCPI Command Reference
:CALC{1-4}:TRAN:DIST:STOP
:CALC{1-4}:TRAN:DIST:STOP
Syntax :CALCulate{[1]|2|3|4}[:SELected]:TRANsform:DISTance:STOP <numeric>
:CALCulate{[1]|2|3|4}[:SELected]:TRANsform:DISTance:STOP?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4), sets the stop value of
the fault location display.
Parameters
If the specified parameter is out of the allowable setup range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric}<newline><^END>
Example of use 10 OUTPUT 717;":CALC1:TRAN:DIST:STOP 9.8357"
20 OUTPUT 717;":CALC1:TRAN:DIST:STOP?"
30 ENTER 717;A
Related commands :CALC{1-4}:TRAN:TIME:STOP on page 139
:CALC{1-4}:TRAN:DIST:STAR on page 120
:CALC{1-4}:TRAN:DIST:STAT on page 121
Equivalent key [Analysis] - Fault Location - Stop
<numeric>
Description Stop value
Range Varies depending on the frequency span, velocity factor, distance
unit, and the number of points.
Preset value 9.8357Ft or 2.9979m
Unit Ft (feet) or m (meters)
