Appendix B 127
SCPI Command Reference
:CALC{1-4}:TRAN:TIME
:CALC{1-4}:TRAN:TIME
Syntax :CALCulate{[1]|2|3|4}[:SELected]:TRANsform:TIME[:TYPE] {BPASs|LPASs}
:CALCulate{[1]|2|3|4}[:SELected]:TRANsform:TIME[:TYPE]?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4), selects the
transformation type used for the transformation function of the fault location function.
Parameters
Query response {BPAS|LPAS}<newline><^END>
Example of use 10 OUTPUT 717;":CALC1:TRAN:TIME LPAS"
20 OUTPUT 717;":CALC1:TRAN:TIME?"
30 ENTER 717;A$
Related commands :CALC{1-4}:TRAN:TIME:STIM on page 138
:CALC{1-4}:TRAN:TIME:STAT on page 136
:CALC{1-4}:TRAN:DIST on page 112
Equivalent key [Analysis] - Fault Location - Type - Bandpass|Lowpass Step|Lowpass Imp.
NOTE When performing this operation from the front panel, you select the stimulus type at the
same time.
Description
BPASs (preset value)
Specifies the band-pass
*1
.
LPASs
Specifies the low-pass
*2
.
*1.You do not need to select the stimulus type. Impulse is selected automatically.
*2.You need to select the stimulus type (impulse or step) with the
:CALC{1-4}:TRAN:TIME:STIM command.
