144 Appendix B
SCPI Command Reference
:CALC{1-4}:SRL:CONN{1-2}:CAP
:CALC{1-4}:SRL:CONN{1-2}:CAP
Syntax :CALCulate{[1]|2|3|4}:SRL:CONNector{[1]|2}:CAPacitance <numeric>
:CALCulate{[1]|2|3|4}:SRL:CONNector{[1]|2}:CAPacitance?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4), sets the connector
capacitance value for the connector mismatch compensation.
Parameters
If the specified parameter is out of the allowable setup range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric}<newline><^END>
Example of use 10 OUTPUT 717;":CALC1:SRL:CONN1:CAP 1e-1"
20 OUTPUT 717;":CALC1:SRL:CONN1:CAP?"
30 ENTER 717;A
Related commands :CALC{1-4}:SRL:CONN{1-2}:IMM on page 145
:CALC{1-4}:SRL:CONN{1-2}:IMP? on page 145
:CALC{1-4}:SRL:CONN{1-2}:LENG on page 146
Equivalent key [Analysis] - SRL - Portx Connector - Capacitance
<numeric>
Description Connector capacitance value
Range -2e-012 to 2e-012
Preset value 0
Unit F
