166 Appendix C
COM Object Reference
SCPI.CALCulate(Ch).SELected.TRANsform.DISTance.SPAN
SCPI.CALCulate(Ch).SELected.TRANsform.DISTance.SPA
N
Object type Property
Syntax SCPI.CALCulate(Ch).SELected.TRANsform.DISTance.SPAN = Val ue
Val ue = SCPI.CALCulate(Ch).SELected.TRANsform.DISTance.SPAN
Description For the active trace of channels 1 to 4 (Ch), sets the span value of the fault location display.
Variable
For information on the variable (Ch), see Table C-2, “Variable (Ch),” on page 159.
Examples Dim Span As Double
SCPI.CALCulate(1).PARameter(1).SELect
SCPI.CALCulate(1).SELected.TRANsform.DISTance.SPAN = 1E-8
Cent = SCPI.CALCulate(1).SELected.TRANsform.DISTance.SPAN
Related objects SCPI.CALCulate(Ch).SELected.TRANsform.DISTance. CENTer on page 159
SCPI.CALCulate(Ch).SELected.TRANsform.DISTance.STATe on page 168
Equivalent key [Analysis] - Fault Location - Span
Value
Description Span value
Data type Double precision floating point type (Double)
Range Varies depending on the frequency span, velocity factor, distance unit, and the number of
points.
Preset value 19.671 Ft or 5.9958 m
Unit Ft (Feet) or m (Meters)
Note If the specified variable is out of the allowable setup range, the minimum value (if the lower
limit of the range is not reached) or the maximum value (if the upper limit of the range is
exceeded) is set.
