3-31
Replaceable Parts
Cables
Attenuator View
Reference
Designator
HP Part Number Qty Description
W1 8120-6758 1 I IN to Daughterboard (A15J2)
W2 8120-6758 1 Q IN to Daughterboard (A15J3)
W6 8120-6758 1 EXT 1 to Daughterboard (A15J4)
W7 8120-6758 1 EXT 2 to Daughterboard (A15J5)
W8 8120-6758 1 LF OUTPUT to Daughterboard (A15J6)
W9 E4400-20018 1 RF OUTPUT to Electronic Attenuator/RPP (AT1)
W11 E4400-60059 1 Output Board (A9) to Synthesizer/Doubler Board (A12) (includes cable retainer and ring)
W12 E4400-60060 1 Output Board (A9) to COHERENT CARRIER (includes cable retainer and ring)
W13 8120-6837 1 Electronic Attenuator/RPP (AT1) to CPU/Motherboard (A14J14)
W14 E4400-60061 1 Electronic Attenuator/RPP (AT1) to Output Board (A9) (includes cable retainer and ring)
