6-29
Error Messages
ESG-D Series Signal Generator Instrument-Specific Error Messages
-222 Data out of range;value clipped to lower limit.
Indicates that an input value is below the minimum value allowed. Examples are:
frequency setting, reference, or offset; output power; power reference and offset;
modulation depth, deviation, or modulation source frequency; number of points and
start/stop values for list mode; start/stop values for internal I/Q calibration; sequence or
register values (save/recall); dwell time.
Data out of range;value clipped to upper limit.
Indicates that an input value is above the maximum value allowed. Examples are:
frequency setting, reference, or offset; output power; power reference and offset;
modulation depth, deviation, or modulation source frequency; number of points and
start/stop values for list mode; start/stop values for internal I/Q calibration; sequence or
register values (save/recall); dwell time.
Data out of range;Synthesizer: Frequency out of bounds.
Indicates that the instrument received an internal request for a frequency outside of its
supported frequency range. Report the circumstances to the factory.
Data out of range;Manual point exceeds list sizes. Limiting to
maximum point.
Indicates that the sweep/list manual point has been reassigned to a smaller number value
due to the longest list decreasing in size or being turned off. Its new value is the length of
the longest enabled list (frequency or power).
Data out of range;Manual point exceeds frequency list size.
Limiting to maximum point.
Indicates that the sweep/list manual point has been reassigned to a smaller number value
due to the longest list decreasing in size or being turned off. Its new value is the length of
the frequency list which is the longest enabled list.
Data out of range;Manual point exceeds power list size. Limiting
to maximum point.
Indicates that the sweep/list manual point has been reassigned to a smaller number value
due to the longest list shrinking, or being turned off. Its new value is the length of the
power list, which is the longest enabled list.
-223
Too Much Data;The number of list points exceeds the maximum
allowed.
Indicates that a SCPI list has been entered that is longer than the maximum allowed
length, which is also the maximum number of step points; too many points were given
for a frequency, amplitude, or dwell time list. This error can also be caused by
