Agilent Technologies ESG-D Series User Manual

6-39
Error Messages
ESG-D Series Signal Generator Instrument-Specific Error Messages
Calibration failure;’Marble Cal’, ‘Offset Cal’, ‘Other Cal’,
‘Gain Cal’, ‘BBG Cal’
Indicates that, while executing the internal I/Q calibration, a failure occurred during the
section indicated.
600
RPP has tripped.
Indicates that the reverse power protection circuit has been triggered. Repeated tripping
of this circuit can cause damage to the instrument.
601
Power search failed.
Indicates that, while executing power search, the level meter circuit failed to return a
meaningful value. This event indicates that the power is in a range that the leveling loop
cannot properly level. The power will be set to the last properly leveled power.
605
DSP FW download failed.
Indicates that the instrument’s firmware was unable to successfully initialize the internal
DSP. Report the circumstances to the nearest HP Sales and Service office.
606
DSP times out.
Indicates that the DSP failed to respond within the appropriate amount of time. Report
the circumstances to the nearest HP Sales and Service office.
607
DSP returns error.
Indicates that the DSP is in an indeterminate state. Report the circumstances to the
nearest HP Sales and Service office.
608
DSP in use by other process.
Indicates that the DSP is in an indeterminate state. Report the circumstances to the
nearest HP Sales and Service office.
615
New wave shape changes limit for internal frequency;frequency
changed to new limit.
When using the internal modulation source, the upper limit varies for the different
waveforms. If the user changes the waveform when the internal source frequency is
higher than that allowed for the new waveform, the frequency for the source will be
changed, and the user informed of that change with this message.
617
Configuration error; Data Generator Memory configuration does not
match installed board.
This indicates that the memory configuration for an option board does not match the
known memory limits of the board. If this error has occurred as the result of a customer-
