Replaceable Parts
Cables
NOTE: W1 through W9 are not present on the front panel with Option 1EM.
Inside Front Panel View
Reference
Designator
HP Part Number Qty Description
A1W1
1
1. This cable is not replaceable by itself. You must order the corresponding assembly.
(part of A1) 1 Front Panel Board (A1) to CPU/Motherboard (A14J20)
A2DS1W1
1
(part of A2DS1) 1 Florescent Lamp (A2DS1) to A3W2
A3W1
1
(part of A3) 1 Inverter (A3) to CPU/Motherboard (A14J19)
A3W2
1
(part of A3) 1 Inverter (A3) to A2DS1W1
B1W1
1
(part of B1) 1 Small Fan (B1) to CPU/Motherboard (A14J16)
B2W1
1
(part of B2) 1 Large Fan (B2) to CPU/Motherboard (A14J17)
W1 8120-6758 1 I IN to Daughterboard (A15J2)
W2 8120-6758 1 Q IN to Daughterboard (A15J3)
W3 8120-5401 1 DATA to Baseband Generator (A7P100) (Options 1EH, UN3, UN4)
W4 8120-5401 1 DATA CLOCK to Baseband Generator (A7P103) (Options 1EH, UN3, UN4)
W5 8120-5401 1 SYMBOL SYNC to Baseband Generator (A7P101) (Options 1EH, UN3, UN4)
W6 8120-6758 1 EXT 1 to Daughterboard (A15J4)
W7 8120-6758 1 EXT 2 to Daughterboard (A15J5)
W8 8120-6758 1 LF OUTPUT to Daughterboard (A15J6)
W9 E4400-20018 1 RF OUTPUT to Electronic Attenuator/RPP (AT1)
W10 8120-6759 1 Display (A2) to CPU/Motherboard (A14J21)
