50 Agilent InfinityLab LC Series 1260 Infinity II FLD User Manual
2
Site Requirements and Specifications
Performance Specifications
Flow cells Standard: 8 µL volume and 20 bar
(2 MPa) pressure maximum, fused silica
block
Analog outputs Recorder/integrator: 100 mV or 1 V,
output range > 100 LU, two outputs
100 LU is the
recommended range
Instrument Control LC & CE Drivers A.02.14 or above
Instrument Control Framework (ICF)
A.02.03 or above
InfinityLab LC Companion (G7108AA)
with firmware D.07.25 or above
Instant Pilot (G4208A) with firmware
B.02.19 or above
Lab Advisor software B.02.09 or above
For details about
supported software
versions refer to the
compatibility matrix of
your version of the LC
and CE Drivers
Communications Controller-area network (CAN), USB, ERI:
ready, start, stop and shut-down signals
Safety features and
maintenance
Leak detection, safe leak handling, leak
output signal for shutdown of the
pumping system.
No hazardous voltages in major
maintenance areas.
Extensive diagnostics, error detection
and display with Agilent Lab Advisor
software.
GLP features Early maintenance feedback (EMF) for
continuous tracking of instrument usage
in terms of lamp burn time with
pre-defined and user settable limits and
feedback messages.
Electronic records of maintenance and
errors.
Housing All materials are recyclable.
Table 5 Performance Specifications 1260 Infinity II Fluorescence Detector (G7121A)
Type Specification Comments
