Regulatory Information C
Advisor Mainframe Features System Guide 111
Safety Information for Laser Source Modules
Class 1 Laser Product: J2901A
Parameter Specification
Laser Type Vertical Cavity Surface Emitting
laser (VCSEL)
Laser Class -
21CFR 1040.10 (Canada, Japan, USA) Class 1
IEC825 (Europe) Class 1
Transmitter Min. Typical Max.
Avg. Optical Power (dBm) -10.0 -7.5 -4.0
Optical Wavelength (nm) 830 845 860
Receiver Min. Typical Max.
Optical Sensitivity (dBm) l -19.0 -17.0
Peak Input Power (dBm) ll0
Optical Wavelength (nm) 770 l 860
You must return modules with malfunctioning lasers to an Agilent
Technologies Service Center for repair and calibration.
Under no circumstances look into the module connector or the end of an
optical cable attached to the optical output when the device is
operational.
