112 Advisor Mainframe Features System Guide
C Regulatory Information
Class 1 Laser Products: J2912A, J2912B
Parameter Specification
Laser Type FP-Laser InGaAsP
Laser Class -
21CFR 1040.10 (Canada, Japan, USA) Class 1
IEC825 (Europe) Class 1
Transmitter Min. Typical Max.
Avg. Optical Power (dBm) -12.0 -10.0 -5.0
Optical Wavelength (nm) 1260 1310 1360
Receiver Min. Typical Max.
Optical Sensitivity (dBm) -28.0 -32.0 l
Peak Input Power (dBm) ll-3.0
Optical Wavelength (nm) 1240 l 1650
You must return modules with malfunctioning lasers to an Agilent
Technologies Service Center for repair and calibration.
Under no circumstances look into the module connector or the end of an
optical cable attached to the optical output when the device is
operational.
