36 Agilent N5181A/82A MXG Signal Generators User’s Guide
Basic Operation
Viewing, Saving, and Recalling Data
Viewing a Stored File
Files Stored in the Signal Generator
1. Press File > Catalog Type > desired catalog.
The files in the catalog appear in alphabetical order. File information includes the file:
•name
•type
•size
• modification date and time
Files Stored on External Media
1. Connect the external media.
The instrument displays the External Media directory.
2. Highlight the USER directory and press Select.
The file directories on the external media appear in alphabetical order, as shown in the following
figure.
se the Page Up and Page Down
eys to see the contents of the
SER directory.
