58 Agilent N5181A/82A MXG Signal Generators User’s Guide
Using Pulse Modulation (Option UNU)
Figure 6-1 Pulse Softkeys
See page 6
1
See page 61
Latency from the externa
l
pulse input to the pulse
sync output ≈ 50−60 ns.
Width Period
50 ns > 50 ns
20 ns ≤ 50 ns
F
or details on each key, use key help
a
s described on page 23.
D
etermines how the signal generator
r
esponds to an external pulse signal.
N
ormal = high state.
I
nvert = low state.
Low = settled
TTL signal
See also, page 9
and page 10
Select the signal that you want
routed to each output connector.
