60 Agilent N5181A/82A MXG Signal Generators User’s Guide
Using Pulse Modulation (Option UNU)
Pulse Characteristics
Figure 6-2 Adjustable Doublet
Figure 6-3 Trigger Doublet
T
he delay of the first pulse is measured from
t
he leading edge of the external trigger signal.
Delay
Width
RF Output
External
Trigger
The delay of the second pulse is measured from
the leading edge of the first pulse.
Delay
Width
The delay of the second pulse is measured from
the leading edge of the external trigger signal.
Delay Width
RF Output
External
Trigger
The first pulse follows the
external trigger signal.
